Description
The BOMAG BPR 50/55 is a heavy-duty reversible vibratory plate compactor engineered for high-performance compaction of granular soils, crushed aggregate, and paving stones. Its hydrostatic forward and reverse drive provides smooth directional control and excellent maneuverability, while the vibration-isolated guide handle improves operator comfort during extended use. Built with a robust protective frame and durable components, the BPR 50/55 is ideal for road construction, landscaping, trench work, and foundation preparation, delivering powerful compaction with reliable, low-maintenance performance.
| Specification | Details |
|---|
| Model | BPR 50/55 D |
| Machine Type | Reversible Vibratory Plate |
| Operating Weight | 893 lb (405 kg) |
| Working Width | 21.7 in (550 mm) |
| Travel Speed | Up to 89 ft/min (27 m/min) |
| Gradeability | 35% |
| Engine | Hatz 1B30 Diesel |
| Engine Power | 6.7 hp (5.0 kW) |
| Engine Speed | 3,000 rpm |
| Fuel Type | Diesel |
| Frequency | 66 Hz (3,960 vpm) |
| Centrifugal Force | 11,240 lbf (50 kN) |
| Fuel Capacity | 1.3 gal (5.0 L) |
